MAIN FEATURES SUMMARY
- Fully Analog Stereo Mix & Master Processor
- Flexible processing architecture with individually selectable processing blocks
- Every processing section can be independently bypassed
INPUT SECTION:
- Fully controllable stereo input level
- Integrated High-Pass Filter
- Input level metering
- Dedicated Input Insert Point for integrating external analog processing into the signal chain
PASSIVE EQ:
- Fully analog passive equalization section
- Designed for broad, musical tonal shaping
- Can operate before or after the compressor
- Instant EQ COMP / COMP EQ routing
BUS COMPRESSOR:
- Analog stereo bus compression section
- Designed for mix-bus glue, dynamics control and final mix shaping
- Independently bypassable from the rest of the processing chain
SATURATION:
- Dedicated analog saturation section
- Adds harmonic character and density independently from compression and EQ
- Fully variable and independently bypassable
CLIPPER:
- Dedicated analog clipping section
- Designed for peak control, additional loudness and transient shaping
- Independently bypassable
WIDTH:
- Dedicated stereo width processing
- Allows precise adjustment of the stereo image
- Independently bypassable
OUTPUT SECTION:
- Fully controllable stereo output level
- Output level metering
- Dedicated Output Insert Point
- Output Insert can operate in Stereo or Mid/Side
- Allows external analog processors to be integrated at the final stage of the ngOmniBox processing chain
- Precise final gain staging after the complete processing chain
DIGITAL CONTROL & RECALL:
- Full digital recall of analog parameters
- A/B/C comparison for instant evaluation of different processing settings
- Integrated LCD display for precise visualization of parameter values
- DAW plug-in integration for control, automation and recall directly from your session
- Complete hardware control without sacrificing the analog signal path
SPECS:
- Dimensions: 55x38x27 (cm)
- Weight ~ 7,5kg
