Specifications:
Audio track features
- 16 × stereo or mono audio tracks, or MIDI tracks
- 5 × selectable SRC (audio) machines:
Oneshot
Warp
Stretch
Grid
RePitch
- 5 × selectable FLTR machines:
Multi-Mode
Lowpass 4
Equalizer
Comb
Legacy LP/HP
- 1 × digital base-width filter per track
- 1 × digital overdrive per track
- 1 × digital bit reduction
- 1 × digital sample rate reduction
- 1 × overdrive master effect
- 1 × stereo compressor master effect
- 3 × assignable LFOs per track
- 400 MB sample memory
- 20 GB+Drive storage
- Diverse sample library
MIDI track features
- 4 note polyphony per step
- 16 × assignable CC controls
- 2 × assignable LFOs per track
Performance features
- 4 × Trig modes
Tracks
Velocity
Retrigs (only works on audio tracks)
Preset pool (only works on audio tracks)
- Keyboard mode with 36 different scales
- Song Mode
Sequencer features
- 128 steps per pattern and track
- Individual pattern length per track
- Individual time scale multiplier per track
- Parameter locks
- Trig conditions & trig chance
- Retrig (audio tracks only)
- Micro timing
- 1 × Euclidean sequence generator per track
Send effects
- Saturator Delay
- Supervoid Reverb
- Panoramic Chorus
Hardware
- 128 × 64 pixel OLED screen
- 2 × ¼” impedance balanced audio out jacks
- 2 × ¼” impedance balanced audio in jacks
- 1 × ¼” stereo headphone jack
- 48 kHz, 24 bit D/A and A/D converters
- Hi Speed USB 2.0 port
- MIDI In/Out/Thru with DIN Sync out
Physical specifications
- Sturdy steel casing
- Dimensions: W 215 × D 176 × H 63 mm (8.5′′ × 6.9′′ × 2.5′′) (including knobs and feet)
- Weight: approximately 1.48 kg (3.25 lbs)
- 100 × 100 mm VESA mounting holes. Use M4 screws with a max length of 7 mm.
Miscellaneous
- Overbridge enabled
- Class Compliant USB Audio
- External Input mixer
- 3 year Elektron warranty
Included in the box
- Power Supply PSU-3c
- Elektron USB cable
- Exclusive artwork
