Algam Lighting Moving Beam 80

MB80 – 80W LED Beam Moving Head

Compact beam fixture for stage and event use

The MB80 is a beam-type moving head fixture equipped with an 80W white LED, designed for professional use in medium-sized events, stages, and club settings where tight beam effects are required.

Gobo and color wheels with motorized focus

It includes a gobo wheel with 12 patterns and a color wheel with 8 colors. A motorized focus enables precise projection and effect control.

Dual rotating prisms

The fixture features two separate prisms – a 6-face and a 12-face – offering varied beam splitting and rotation at adjustable speeds for added effect layers.

Motion and control options

With fast PAN (540°) and TILT (230°) movement, the MB80 supports dynamic light positioning. It offers multiple operation modes: DMX, sound-activated, automatic, and master/slave.

Specifications

• Light source: 80W white LED

• Gobo wheel: 12 gobos

• Color wheel: 8 colors

• Prism: Dual (6-face + 12-face), rotating

• Focus: Motorized

• Movement: PAN 540° / TILT 230°

• Operation modes: Auto, sound, DMX, master/slave

• Protection rating: IP20 (indoor use)

• Dimensions: 195 x 170 x 280 mm

• Weight: 3 kg
